Dark Grey Enclosure with Mounting Flange - 171(W) x 121(D) x 55(H)mm
- Cat No:
- HB6125
In Stock
$29.90
Description
Features:
• Operating temperature: -20 to 80 degrees
• Bosses on internal base allow fixing of PCBs horizontally, or connection of terminals etc.
• The lid and base incorporate a tongue and groove sealing system with a EPDM gasket
• Lid fixing screws are M-4 stainless steel (non-magnetic) into threaded brass inserts
• Wall mounting holes and lid fixing screws are outside the sealing area thus preventing the ingress of moisture and dust
Specifications
- Material
- ABS Plastic (Acrylonitrile Butadiene Styrene)
- PCB Internal Guide Slots
- true
- Internal Mounting Posts
- true
- Gasket sealing system
- true
- Gasket Material
- Neoprene
- Ventilation Holes
- false
- Colour
- Dark Grey
- IP Rating
- IP65
- Dust/Particle Ingress Protection
- 6 - Dust tight, no ingress of dust
- Liquid/Moisture Ingress Protection
- 5 - Water jets
- Width
- 171.0mm
- Height
- 55.0mm
- Depth
- 121.0mm
- Dimensions details
- Base Dimensions
- Width
- 201.0mm
- Depth
- 121.0mm
- Packaged Dimensions
- 22.1cm(Length) x 14.3cm(Width) x 5.9cm(Height)
