KINGRAY
Kingray 25dB VHF Masthead Amplifier, Separate or Combined input with 4G/LTE filter
- Cat No:
- 510003
- MPN:
- MHV25F
Sold as:1 Each
Out of Stock$99.90
Description
The MHV25F is a VHF TV masthead amplifier, specifically designed to work in areas where there is VHF transmission only. With band 1, 2, 4 and 5 filtering, it ensures ensure only channels 6 to 12 (174 MHz to 230 MHz) are amplified, eliminating all unwanted frequencies including those in the 4G/LTE band.
The masthead is powered remotely via a Kingray PSK06 or PSK08 series power supply (sold separately).
Key Features:
- Frequency Range 174-230 MHz
- 25dB Maximum Gain
- 10dB Gain Control
- Single VHF Input
- Weatherproof Housing
- High Output Figure of 105dB IMR3 (DIN45004B)
- Connectors: F-Type
- Power Consumption: 60mA
- Suitable Power Supply: PSK06 Series or PSK08 Series
The masthead is powered remotely via a Kingray PSK06 or PSK08 series power supply (sold separately).
Key Features:
- Frequency Range 174-230 MHz
- 25dB Maximum Gain
- 10dB Gain Control
- Single VHF Input
- Weatherproof Housing
- High Output Figure of 105dB IMR3 (DIN45004B)
- Connectors: F-Type
- Power Consumption: 60mA
- Suitable Power Supply: PSK06 Series or PSK08 Series
Specifications
- •
- MHV25F
- •
- Cable Tie
- •
- Instruction Manual
- Product Dimensions
- 0.0 x 0.0 x 0.0 mm
- Width
- 0.0mm
- Diameter
- 0.0mm
- Weight
- 0.0g
- Packaged Dimensions
- 12.4cm(Length) x 13.7cm(Width) x 5.0cm(Height)
