Terminal Barrier PCB with Clear Cover 6 Way
- Cat No:
- HM3164
Sold as:1 Each
In Stock$8.20
Description
Barrier Material: Thermoplastic (UL=94V-0), Black
Terminals: Tint Plated Brass (Standard)
Screws: Nickel Plated Steel
Wire Range AWG: 12-22 STR
Cover Material: PC
Insulation withstands voltage AC 2000V/Min
Pole HD-12-? P HD-12-? PH
A (Px9.5)+1.4 (P+2)*9.5+1.4
B (P-1)*9.5 (P+1)*9.5
Terminals: Tint Plated Brass (Standard)
Screws: Nickel Plated Steel
Wire Range AWG: 12-22 STR
Cover Material: PC
Insulation withstands voltage AC 2000V/Min
Pole HD-12-? P HD-12-? PH
A (Px9.5)+1.4 (P+2)*9.5+1.4
B (P-1)*9.5 (P+1)*9.5
Specifications
- Type
- Screw Terminal
- Device
- Terminal
- Attachment Method
- PCB
- Number of Contacts
- 6.0pc
- Terminal Spacing
- 9.5mm
- Insulation Dielectric Voltage Rating
- 2.0kV
- Insulation Resistance
- 500.0MΩ
- DC current rating
- 25.0A
- Type
- Terminal Strip
- Device
- PCB Barrier
- Length
- 76mm
- Number of Contacts
- 6.0
- Packaged Dimensions
- 8.0cm(Length) x 1.5cm(Width) x 2.4cm(Height)
